LTM 45 (M)


          LTM 45 (M)

Characteristics:


  • travel range 25 mm, 40 mm, 65 mm, 85 mm and 110 mm
  • designed for industrial applications
  • ground fine-thread spindle with low backlash
  • carriage with ground and stainless recirculating ball bearing guides
  • Hall-effect or mechanical limit switches
  • 2-phase step motor or DC motor with encoder
  • deformation-resistant aluminium
  • reflection-poor, black anodized




The economically priced linear stages LTM 45 are the slimmest of the LTM series and particularly suitable for continuous operation and installation in machines.



The versions of the LTM 45M are additionally equipped with a metal covering, whereby the bearing guide and spindle are protected.



The special guides provide practically slip-stick free movement as well as high load capacity. The material combination of spindle and nut ensures low abrasion and a long life.



All aluminum parts have a top-quality black anodized protective coating.
